A compound bow is a bow that bends the limbs using a levering mechanism, usually cables and pulleys. In modern archery, compound bows are commonly used for target practice and hunting in general.
A compound bow’s limbs are much stiffer than those of a recurve bow or longbow due to the pulley/cam system, which gives the user a mechanical advantage. Since less energy is dissipated in limb movement, the compound bow is more energy efficient than other bows. The bow’s vulnerability to changes in temperature and humidity is reduced by the higher-rigidity, higher-technology construction.
The pulley/cam system also provides a function known as “let-off.” The cams rotate as the string is pulled out. Since the cams are eccentric instead of circular, their effective radius varies as they rotate. Each of a compound bow’s two cams has two tracks: an inner track that runs through the bowstring and connects to the opposite limb or opposite cam through cables, and an outer track that runs through the opposite limb or opposite cam via cables. The ratio of bowstring pay-out and cable take-up to limb-weight and cam leverage shifts as the bow is drawn. Different draw-stroke profiles can be generated by modifying the shapes of these cam tracks.
Table of Contents
- 1 Compound Bow FAQ
- 1.1 How Much Does A Compound Bow Weight?
- 1.2 How To Change Poundage On A Compound Bow?
- 1.3 How Do You Adjust A Compound Bow?
- 1.4 Can You Use Compound Bow Broadheads On A Crossbow?
- 1.5 How To Aim A Compound Bow Without A Peep Sight?
- 1.6 How To Draw Back A Compound Bow?
- 1.7 SAS Destroyer Extended Review
- 1.8 SA Sports Youth Panther Compound Bow Set Reviews
- 1.9 How to shoot FISH with a Bow |Bowfishing
- 1.10 Top 5 Nxt Generation Compound Bows [2018]: Nxt Generation Gatlin Bow, Black
- 1.11 2019 Mathews Vertix Compound Bow With Switchweight Technology Review
- 1.12 Best Beginner Compound Bow – Top 5 Best Compound Bow For Beginners
- 2 Construction
- 3 Technical Advantages
- 4 Technical Disadvantages
- 5 Circumstantial Advantages
- 6 Circumstantial Disadvantages
- 7 Specifications
- 8 Arrows
- 9 Bestselling Products
- 9.1 Bear Archery Cruzer G2 Compound Bow with RealTree Edge Finish
- 9.2 PANDARUS Compound Bow Draw 0-70 LB for Pull Beginner and Intermediate Archer Fully Adjustable 19.25"~31" with All Accessories New 2022 (Black)
- 9.3 PANDARUS Compound Bow Archery for Youth and Beginner, Right Handed,19”-28” Draw Length,15-29 Lbs Draw Weight, 260 fps (Black Right Handed)
- 9.4 Sanlida Archery Dragon X8 RTH Compound Bow Package for Adults and Teens,18”-31” Draw Length,0-70 Lbs Draw Weight,up to IBO 310 fps,No Bow Press Needed,Limbs Made in USA,Limited Life-time Warranty
- 9.5 XGeek Compound Bow and Arrow kit, Hunting & Target Bow, with All Accessories, USA-Made Limbs, Draw Weight Adjustable 20-70 Lbs, Draw Length 17-29", 320 Fps Speed,for Hunter and Archery Enthusiast
- 9.6 Bear Archery Limitless Dual Cam Compound Bow - Includes Quiver, Sight and Rest, God's Country
- 9.7 Diamond Archery Infinite Edge Pro Bow Package, Black Ops, Right Hand
- 9.8 AW 70 Lbs Pro Compound Right Hand Bow Kit Arrow Archery Target Hunting Camo Set
- 9.9 DJH Archery Compound Bow Package for Adults and Teens, 19inch-30inch Draw Length,19-70Lbs Draw Weight,320fps IBO,Gordon Composites Limbs,Limbs Made in USA (Forest)
- 9.10 Topoint Trigon Compound Bow Full Package,CNC Milling Riser,USA Gordon Composites Limb,BCY String,19"-30" Draw Length,19-70Lbs Draw Weight,IBO 320fps (Ghost)
- 9.11 Diamond Archery Edge 320 Compound Bow - Purple Blaze - 70 lbs, Left Hand
- 9.12 Bear Archery Kuma Compound Bow Right Hand 70lbs 345 FPS ATA 33"
- 9.13 SinoArt Compound Bow 30-55lbs 24"-29.5" Archery Hunting Equipment Max Speed 310fps with Accessories Right Handed
- 9.14 XGeek Compound Bow,Compound Hunting Bow Kit,CNC Milling Bow Riser,Limbs Made in USA,19"-30" Draw Length,19-70Lbs Draw Weight,Up to 320FPS, (2 Years Warranty)Ship from USA Warehouse (Delivery 2-3 days)
- 9.15 Bear Archery Rant RTH Compound Bow, CAMO
- 9.16 Youth Compound Bow Set 15-45lbs for Teens, Package with Archery Hunting Equipment Max Speed 320fps, Adjustable, Right Hand (Camo)
- 9.17 2021 Compound Bow and Arrow for Adults and Teens – Hunting Bow with Gordon Limbs Made in USA - Fully Adjustable for Women and Youth 30-70 LBS, 23.5-30.5” - 320 FPS Speed – 5-Pin Sight, Quiver - Left
- 9.18 Southland Archery Supply SAS Feud 70 Lbs Compound Bow Target Field (Camo with Pro Package) (Black Bow Only)
- 9.19 GENESIS Kit - RH Black
- 9.20 Diamond Archery Infinite Edge Pro Package Breakup Country Left Hand 5-70 lbs
Compound Bow FAQ
How Much Does A Compound Bow Weight?
How To Change Poundage On A Compound Bow?
How Do You Adjust A Compound Bow?
Can You Use Compound Bow Broadheads On A Crossbow?
How To Aim A Compound Bow Without A Peep Sight?
How To Draw Back A Compound Bow?
A soft-drawing compound bow may have a gradual build-up to peak weight and a gradual let-off with a long "valley" at the top. It can also be hard-drawing, with a rapid build-up to peak draw-weight, a long plateau where weight is retained, and a short valley. The let-off is caused by the cam profiles passing through center and entering a state similar to a cam-lock. If the draw-stops or draw-length modules are removed from certain compound bows, they will self-lock at full draw and require professional equipment to safely unlock. When pulled to full draw, several compound bows give 70–85 percent let off. This helps the shooter to unwind and focus on the intended target.
- Tart Aiming & Firing Right Away – Package contains 1 main bow body, 10 suction cup arrows, target and quiver. 2*AA batteries needed(not included).
- More Attractive Outdoor Toy - The archery set with led light is one of the favorite outdoor toys for kids.The LED lights make you track the trace of arrow in the night easily and add some cool effect.
- Educational & Fun - Kids will practice their accuracy skills, hand-eye coordination, fine motor skills and aim right on target in the most fun and interactive way.
- Durable Design - Premium elasticity material of bows and arrows ensure its durable features, not easily broken. It has a smooth surface, which makes it safe for children. Sucker can be adsorbed on the smooth glass, wall, and targets(provided).
- Gift Ideas - Easy to wear quiver with strap, you can enjoy it even travelling or camping. Perfect for kids/ boys/ girls birthday party, indoor outdoor activity, christmas gifts toys for kids, boys christmas gifts, birthday gifts, Thanksgiving gifts, Halloween gifts.This is a safe and fun outdoor activity for everyone!
- New Upgrade Version Kids Bow And Arrow Set - Includes 2 x main bow body (Green and Blue), 20 x suction cup arrows, 2 x target and 2 x adjustable shoulder strap quiver.
- Night LED Light Cool Toys - This archery set with LED lights is perfect for you and your kids in indoor activities or outdoor games. After inserting 2 AA batteries (not included), press the button to turn on the LED lights, allowing children to easily track the arrows at night, enjoy a wonderful shooting game.
- Education and sports development - this set of bows and arrows is suitable for children to play together, learn to take turns and encourage sharing, it is also very suitable for parent-child games, guide children to target practice, exercises physical coordination and fine motor skills, promote healthy growth and increase confidence.
- High-Quality Safety Structure - We understand the importance of kid s safety, so our archery set suits are made of non-toxic and durable materials, the right angles use radians smooth design, the arrow selects the vacuum soft rubber suction cup, Sucker can be adsorbed on the smooth glass, wall, and targets(provided).
- Perfect Gift For Kids - This bow and arrow set is definitely the perfect gift for children! Suitable for all seasons, and easy to carry to any place to play. Equipped with exquisite gift boxes, it is very suitable for Kids Christmas gifts, birthday gifts, birthday party supplies and Thanksgiving gifts, this will be the gift that will make you the favorite parent, aunt, uncle or grandma!
- BARNETT 20 HEADHUNTER ARROWS 5-PACK: Carbon arrows specifically made for superior performance. Each arrow includes field points and half-moon nocks. 1-ounce arrows have strong, lightweight carbon shafts; improved wall thickness for added durability
- SUPERIOR ACCURACY: Arrows are 13.78 grains per inch, matched with 100-grain point to create optimal accuracy and target penetration. Pack also includes 24F field point and moon nocks
- COMPATIBLE: Can be used with Ghost 350, Penetrator, Wildcat C-5, Jackal, Whitetail hunter II, Raptor FX3 crossbows, and other models that take a 20 inch Arrow
- SPECS: Length 20 , 13.78 grains per inch, matched with 100-grain point, includes 24F field point and moon nocks, 5-pack, color is black
- BARNETT: The most trusted name in crossbows since 1962
- for use in the Ghost 350, Penetrator, Wildcat C-5 and Jackal
- PRECISION - Rage broadheads are known for their accuracy and their legendary wound channels
- MASSIVE CUTTING SURFACES – Rear-deploying, SlipCam design with huge leading-edge blade and razor sharp .035 thick stainless steel expandable blades. 2 cutting diameter. 125 Grain
- TECHNOLOGY - Improved Shock Collar Technology ensures proper blade retention while bolt is stored and in-flight and allows for broadhead to open upon impact – FERRULE ALIGNMENT TECHNOLOGY - F.A.T. ensures a more aerodynamic bolt flight
- BENEFITS - Flies like a field tip. Specifically designed for use with CrossBows. 3 PACK - Available in 100 or 125 Grain. Replacement Blade R53005 (not included); Made in the USA
- RAGE - Leading the Evolution in Mechanical broadheads
- BARNETT ROPE COCKING DEVICE FOR CROSSBOW: This tool is made to simplify cocking any crossbow by decreasing the cocking tension in half. The handles allow for a firm hold, and the rope may be adjusted to fit both the bow and user
- ACCURACY: Ensures bow is evenly cocked for maximum accuracy
- ADJUSTABLE: Rope cocking device be adjusted to fit both the crossbow and the user
- COMPATIBLE: Works with all standard draw Barnett crossbows but does not work for any Barnett Reverse Draw Cam bows. Barnett models that this item is not compatible with include: 78246, 78061, 78057, 78201, 78205, 78230, 78210 & 78212
- BARNETT: The most trusted name in crossbows since 1962
- Compatible with all standard draw Barnett crossbows but does not work for any Barnett Reverse Draw/Cam bows. Barnett Models that this item is not compatible with include 78246, 78061, 78057,78201,78205, 78230, 78210 & 78212.
- Tart Aiming & Firing Right Away – Package contains 1 main bow body, 10 suction cup arrows, target and quiver. 2*AA batteries needed(not included).
- More Attractive Outdoor Toy - The archery set with led light is one of the favorite outdoor toys for kids.The LED lights make you track the trace of arrow in the night easily and add some cool effect.
- Educational & Fun - Kids will practice their accuracy skills, hand-eye coordination, fine motor skills and aim right on target in the most fun and interactive way.
- Durable Design - Premium elasticity material of bows and arrows ensure its durable features, not easily broken. It has a smooth surface, which makes it safe for children. Sucker can be adsorbed on the smooth glass, wall, and targets(provided).
- Gift Ideas - Easy to wear quiver with strap, you can enjoy it even travelling or camping. Perfect for kids/ boys/ girls birthday party, indoor outdoor activity, christmas gifts toys for kids, boys christmas gifts, birthday gifts, Thanksgiving gifts, Halloween gifts.This is a safe and fun outdoor activity for everyone!
- New Upgrade Version Kids Bow And Arrow Set - Includes 2 x main bow body (Green and Blue), 20 x suction cup arrows, 2 x target and 2 x adjustable shoulder strap quiver.
- Night LED Light Cool Toys - This archery set with LED lights is perfect for you and your kids in indoor activities or outdoor games. After inserting 2 AA batteries (not included), press the button to turn on the LED lights, allowing children to easily track the arrows at night, enjoy a wonderful shooting game.
- Education and sports development - this set of bows and arrows is suitable for children to play together, learn to take turns and encourage sharing, it is also very suitable for parent-child games, guide children to target practice, exercises physical coordination and fine motor skills, promote healthy growth and increase confidence.
- High-Quality Safety Structure - We understand the importance of kid s safety, so our archery set suits are made of non-toxic and durable materials, the right angles use radians smooth design, the arrow selects the vacuum soft rubber suction cup, Sucker can be adsorbed on the smooth glass, wall, and targets(provided).
- Perfect Gift For Kids - This bow and arrow set is definitely the perfect gift for children! Suitable for all seasons, and easy to carry to any place to play. Equipped with exquisite gift boxes, it is very suitable for Kids Christmas gifts, birthday gifts, birthday party supplies and Thanksgiving gifts, this will be the gift that will make you the favorite parent, aunt, uncle or grandma!
- BARNETT 20 HEADHUNTER ARROWS 5-PACK: Carbon arrows specifically made for superior performance. Each arrow includes field points and half-moon nocks. 1-ounce arrows have strong, lightweight carbon shafts; improved wall thickness for added durability
- SUPERIOR ACCURACY: Arrows are 13.78 grains per inch, matched with 100-grain point to create optimal accuracy and target penetration. Pack also includes 24F field point and moon nocks
- COMPATIBLE: Can be used with Ghost 350, Penetrator, Wildcat C-5, Jackal, Whitetail hunter II, Raptor FX3 crossbows, and other models that take a 20 inch Arrow
- SPECS: Length 20 , 13.78 grains per inch, matched with 100-grain point, includes 24F field point and moon nocks, 5-pack, color is black
- BARNETT: The most trusted name in crossbows since 1962
- for use in the Ghost 350, Penetrator, Wildcat C-5 and Jackal
- PRECISION - Rage broadheads are known for their accuracy and their legendary wound channels
- MASSIVE CUTTING SURFACES – Rear-deploying, SlipCam design with huge leading-edge blade and razor sharp .035 thick stainless steel expandable blades. 2 cutting diameter. 125 Grain
- TECHNOLOGY - Improved Shock Collar Technology ensures proper blade retention while bolt is stored and in-flight and allows for broadhead to open upon impact – FERRULE ALIGNMENT TECHNOLOGY - F.A.T. ensures a more aerodynamic bolt flight
- BENEFITS - Flies like a field tip. Specifically designed for use with CrossBows. 3 PACK - Available in 100 or 125 Grain. Replacement Blade R53005 (not included); Made in the USA
- RAGE - Leading the Evolution in Mechanical broadheads
- BARNETT ROPE COCKING DEVICE FOR CROSSBOW: This tool is made to simplify cocking any crossbow by decreasing the cocking tension in half. The handles allow for a firm hold, and the rope may be adjusted to fit both the bow and user
- ACCURACY: Ensures bow is evenly cocked for maximum accuracy
- ADJUSTABLE: Rope cocking device be adjusted to fit both the crossbow and the user
- COMPATIBLE: Works with all standard draw Barnett crossbows but does not work for any Barnett Reverse Draw Cam bows. Barnett models that this item is not compatible with include: 78246, 78061, 78057, 78201, 78205, 78230, 78210 & 78212
- BARNETT: The most trusted name in crossbows since 1962
- Compatible with all standard draw Barnett crossbows but does not work for any Barnett Reverse Draw/Cam bows. Barnett Models that this item is not compatible with include 78246, 78061, 78057,78201,78205, 78230, 78210 & 78212.
Holless Wilbur Allen of North Kansas City, Missouri, invented the compound bow in 1966, and a US patent was granted in 1969. The compound bow has grown in popularity in recent years and is the most common type of bow in the United States.
Composite bows were referred to as "compound" in early twentieth-century literature until the invention of compound bows. This use is no longer valid.
Construction
The riser is the central mount for other components such as limbs, sights, stabilizers, and quivers on a bow. Risers are made to be as rigid as they can be. A compound bow's central riser is typically made of aluminum, magnesium alloy, or carbon fiber, with many being made of 7075 aluminum alloy.
Limbs are constructed of composite materials based on fiberglass that can withstand high tensile and compressive forces. The bow's energy is contained entirely in the limbs; no energy is stored in the pulleys or cables. Adult compound bows have draw weights ranging from 40 to 80 pounds (18 to 36 kg), allowing arrow speeds of 250 to 370 feet per second (76 to 113 m/s).
Each limb has a cam or wheel at the end of it in the most common configuration. The shape of the cam varies slightly depending on the bow style. There are several different ways to use the cams to store energy in the limbs, all of which are classified as bow eccentrics. Single Cam, Hybrid Cam, Dual Cam, and Binary Cam are the four most common forms of bow eccentrics. Other less common designs, such as the Quad Cam and Hinged, are also available. The "let-off" rating is often used to characterize cams. The force needed to keep the bow in place increases as the cam is rotated, then decreases as the bow reaches full extension (a position known as "the wall"). The "let-off" is the percent difference between the maximum force experienced during the draw and the force needed to keep the bow fully extended. For recently built compound bows, this value is typically between 65 percent and 80 percent of the peak weight, while some older compound bows only offered a 50 percent let-off and some recent designs achieve let-offs in excess of 90 percent.
The axle connecting the limb to the cam is placed at the edge of the cam, rather than in the middle, as seen in the picture on the right. As the string is pulled tighter, the cam rotates, exerting force on the limb. The archer has the'short' side of the cam at first, and the leverage is a mechanical disadvantage. As a result, a large amount of energy is needed. When the archer is near full draw, the cam has turned to its full degree, the archer has gained mechanical advantage, and the string requires the least amount of energy to hold the limbs bent. This is referred to as "letting go." The archer will keep the bow completely drawn and take more time to shoot with the lower holding weight. This let-off helps the archer to fire a compound bow with a much higher peak draw weight than most bows with greater precision (see below).
However, some youth-oriented compound bows with low draw weights, no let-off, and a maximum draw length purposely set farther than the majority of young shooters can reach. The draw length is calculated by the shooter's chosen anchor point, essentially making the bow act like a recurve. This eliminates the need to adjust the draw length of the bow or use a different bow for different shooters (or to change bows as the shooter gets older). The Genesis, which is standard equipment in the US National Archery in the Schools Program, is an example of this type of bow.
Compound bow strings and cables are typically made of high-modulus polyethylene and are constructed to have high tensile strength and limited stretchability, allowing the bow to pass energy to the arrow as quickly and as long as possible. The cables in older models of compound bows were frequently made of plastic-coated material.
Technical Advantages
- The cam systems (also known as 'eccentrics') are designed to optimize energy storage during the draw cycle while also providing let-off at the end (less holding weight at full draw). A typical recurve bow has a very linear draw weight curve, which means that the draw force increases with each inch of draw back (and most difficult at full draw). As a result, only a small amount of energy is stored in the first half of the draw, but a large amount of energy is stored at the end, where the draw weight is the heaviest. The compound bow has a different weight profile, reaching its maximum weight within the first few inches of the draw and then staying more flat and steady until the end of the cycle, when the cams "let-off" and allow for a lower holding weight. Compound bows store more energy and fire faster than comparable peak weight recurve or longbows due to this manipulation of peak weight during the draw (accomplished by the elliptical shape of the cams that adjust leverage and mechanical advantage).
- The arrow's acceleration is directly controlled by the cams' architecture. The arrow can accelerate more softly with a "soft cam" than with a "harder" cam. A soft cam is usually used by novice archers, while a harder cam can be used by more experienced archers to gain speed. Bows are available with a wide range of cams, ranging from soft to heavy.
- Instead of two similar cams, some pulley systems use a single cam at the bottom of the bow and a circular idler wheel at the top of the bow. This design does away with the need for a separate control cable in favor of a single long string that starts at the bottom cam, travels over the top wheel, and returns to the bottom cam. The bottom cam is then attached to the top limb through a separate buss cable.
- The cables pull the limbs in toward each other when a compound bow is drawn, unlike a longbow or recurve, where the limbs flex in the direction of the bow string. Because of this disparity, modern compounds may have limbs that are more horizontal than angled. Since the forces moving upward at the top limb and downward at the bottom limb cancel each other out, the horizontal, or "parallel" limb arrangement minimizes the recoil and vibration felt by the shooter when the arrow is fired.
- Some rubber-covered blocks that serve as draw-stops are typically included in the pulley system. These include a strong "block" from which the archer can draw. These draw stops may be modified to the archer's desired draw length, allowing the archer to maintain a consistent anchor point and amount of force applied to the arrow on every shot, further enhancing accuracy.
Technical Disadvantages
- A greater number of moving parts necessitates further maintenance and raises the probability of failure.
- Due to the greater amount of energy stored and released, dry firing is more likely to damage or kill a compound bow.
- In comparison to conventional bows, replacing the string or cables, as well as changing the let-off or draw length, often necessitates the use of a bow press, a specialized tool for compressing the limbs and relieving tension from the cables and string.
- When drawing a compound bow with the fingers, the bowstring is more likely to be torqued, causing the string to derail from the cams. As a result, mechanical release aids are frequently needed.
- Compound bows are typically heavier than recurves and longbows.
Circumstantial Advantages
- To hold and release the string, compound archers often use a mechanical release aid. This sticks to the bowstring near the nocking point, allowing the archer to release the string with a trigger squeeze or a slight increase in tension. When the bowstring is released directly from the fingertips, arrow oscillation is unavoidable, so using a release aid ensures a more stable release than using fingers on the string.
- Bows with a sighting device, consisting of a "peep sight" kept inside the bowstring that serves as a back sight, are used in tournaments for compound archers, but front sights attached to the riser are used in other classes. For targets at various distances, some front sights are magnifying and/or adjustable. Multiple "sticks" are set up for targets at various distances in certain sights.
Circumstantial Disadvantages
- As compared to a recurve bow, a compound bow's low holding weight makes it more susceptible to some shooting form defects when the archer is at full draw. It's especially easy for the archer to torque (twist) the bow around the vertical axis, resulting in left-right errors, and a plucked or snatched release can have a bigger impact.
Specifications
The normal draw length of the AMO (Archery Manufacturers and Merchants Organization) is the distance between the string at full draw and the lowest point on the grip plus 1.75 inches (4.4 cm). Bows with the same peak draw force will store different quantities of energy because the draw force can increase or decrease more or less rapidly as it reaches peak draw. The stored energy to peak draw force ratio (S.E./P.D.F.) was described by Norbert Mullaney. This is normally about one foot-pound per pound-force (3 joules per kilogram-force), but it can exceed 1.4 foot-pound per pound-force (4.2 J/kgf).
Bow quality varies as well. In most cases, the arrow receives 70–85 percent of the stored energy. Potential energy is the name given to this stored energy. It is referred to as kinetic energy as it is passed to the projectile. The power factor is defined as the product of S.E./P.D.F. and performance. AMO and IBO speed are the two measurement criteria for this quantity. The initial velocity of a 35-gram (540-grain) arrow fired from a bow with a peak draw weight of 270 N (61 pounds-force) and a draw length of 76 cm is referred to as AMO (30 inches). The initial velocity of a 22.7-gram (350-grain) arrow fired from a bow with a peak draw weight of 300 N (67 pounds-force) and a draw length of 76 cm is referred to as IBO pace (30 inches).
The distance between the pivot point of the grip and the string at rest is known as brace height. A shorter brace height usually results in a more powerful stroke, but at the cost of a bow that is less tolerant of shooter error and has sharper string slap.
Arrows
Compound bow arrows are similar to recurve bow arrows in that they are commonly made of aluminum alloy, carbon fiber, or a combination of the two materials. Because of their brittleness, wooden arrows are seldom used on compound bows. The bulk of today's arrows are made of carbon fiber. The arrow spine is a key difference between recurve and compound bows in terms of arrows. Compound bows and target recurve bows with completely center-shot cutaway risers are notoriously forgiving when it comes to choosing a spine. Modern compound bows usually have considerably stiffer arrows than a recurve bow of equal draw length and draw weight. Another benefit of the center-shot riser is that the arrow does not have to curve nearly as much or at all around the riser during the shot. Rather than modifying arrow length and tip weight, fine-tuning can be done by adjusting the arrow rest, or nock point on the string.
To fit various draw weights and lengths, manufacturers create arrow shafts with different weights, spines (stiffness), and lengths in the same type of shaft, suited to archers' different types, tastes, and physical attributes.
Arrow stiffness (spine) varies with both the construction and length of the arrow, and is a critical parameter in finding arrows that will shoot accurately from any bow (see Archer's paradox).
Another point to bear in mind is that the IBO (International Bowhunter Organization) recommends a safety buffer of at least 5 grains per pound (0.71 grams per kilogram) of draw weight. This means that a bow drawing 60 pounds (27 kg) would require a finished-with-tip arrow weighing at least 300 grains (19 grams). Shooting arrows lighter than this guideline can damage the bow in the same way that dry-firing can, resulting in injury to the archer or anyone nearby. Many manufacturer warranties are also invalid if you shoot arrows that are too light.
